Some of the many image-processing machines our software is powering ...

Surface inspection of sheet metal

4 cameras above the moving sheets

Sheets much bigger the viewing field

CAD model of sensitive areas overlayed

Ignores errors in insensitive areas

PC loads current model into the cameras

PC also keeps statistic

Sheets move with up to 1 m / second

Sheet size up to 1250 x 2200 mm

Detects 2 mm wide black pen markings

Ignores reflecting undulating metal surface

Checking the orientation

Camera checks feeding direction

User can teach the requested feature

Camera provides graphical user interface

User controls the camera via Touchscreen

Objects fly by on the conveyor

Camera looks for learned feature

Object diameter 3 - 10 mm

Object length 10 - 65 mm

Detects even small differences

Camera checks about 12 parts per second

Tomato color inspection

2 cameras above the moving tomatoes

Selection for 3 color categories

Setup by a PLC - then camera remembers

Up to 6 tomatoes per camera and second

Sensor cameras used

Inspecting surface and shape

3 cameras arround a rotating glas table

Check upper, lower surface and contour

Small metal or plastic objects checked

More then one machine - different users

PC controls cameras and machine

PC keeps track of objects on the table

Checking speed about 0,5 - 2 s / piece
